- CPU
- AMD Ryzen R1600 (2 cores / 4 threads, 2.6 GHz base / 3.1 GHz boost)
- Bays
- 4× 3.5"/2.5" SATA hot-swap + 2× M.2 NVMe (cache or storage, DSM 7.2+)
- Power
- 100 W external adapter, 35 W typical access / 14 W idle
- Memory
- 4 GB DDR4 ECC SO-DIMM (expandable to 32 GB)
- Network
- 2× 1 GbE (link aggregation / failover), expandable to 10 GbE via optional E10G22-T1-Mini
- Warranty
- 3-year limited (5-year extension available)
- OS / apps
- DSM 7.2 — Synology Drive, Active Backup, Surveillance Station, Container Manager, Hyper Backup, Snapshot Replication
- Form factor
- Desktop tower (166 × 199 × 223 mm), 2.4 kg empty
- RAID levels
- SHR / SHR-2, RAID 0/1/5/6/10/JBOD, Basic
- USB / eSATA
- 2× USB 3.2 Gen 1 + 1× eSATA (for DX517 expansion bay)
- File systems
- Btrfs (data integrity + snapshots) or ext4
- Max capacity
- 144 TB (4× 22 TB) before NVMe expansion
