HinoFM 260 JD

Hino 500 FM 260 JD Truck 6x4

26-tonne GVW 6x4 rigid truck — tipper, cargo and mixer bodies for site and quarry haulage.

Price on request

Specifications

Machine type: Rigid commercial truck, 6×4
Gross vehicle weight: 26 000 kg
Chassis weight: 7 250 kg (cab and chassis)
Engine: Hino J08E-UF, 6-cylinder turbo-intercooled, 7.7 l
Max power: 191 kW (260 hp) @ 2 500 rpm
Max torque: 739 N·m @ 1 500 rpm
Transmission: 9-speed manual (ZF 9S1110)
Rear axle: Double reduction, ratio 6.428
Tyres: 11.00R20, 10 wheels
Suspension: Semi-elliptic leaf, rear bogie
Brakes: Full air, dual circuit, with exhaust brake
Fuel tank: 200 l
Wheelbase: 4 350 / 5 000 mm
Emissions: Euro 3 / Euro 4 depending on market
Body options: Tipper, cargo, mixer, water tank, crane-mounted

Description

The FM 260 JD is the workhorse rigid in Indonesian site haulage: a 6x4 chassis at 26 tonnes GVW, most often bodied as a tipper for aggregate and spoil, or as a mixer for ready-mix supply. The J08E engine at 191 kW is matched to a 9-speed box that keeps the truck loaded on grades without excessive shifting. The chassis is specified in two wheelbases depending on body length and turning requirement. We supply chassis-cab or fully bodied, with the body builder's certification and registration documents included.
