CumminsC220D5

Cummins C220D5 Diesel Generator 220 kVA

220 kVA standby / 200 kVA prime generating set — site power, plant backup and grid-edge supply.

Price on request

Specifications

Machine type: Diesel generating set
Prime power rating (PRP): 200 kVA / 160 kW
Standby power rating (ESP): 220 kVA / 176 kW
Engine: Cummins 6BTAA5.9-G12, 6-cylinder turbo, 5.9 l
Alternator: Stamford / Cummins Generator Technologies, brushless
Base fuel tank: 300 l (≈ 8 h at 100 % prime)
Fuel consumption (prime): ≈ 22 / 30 / 40 l/h at 50 / 75 / 100 % load
Control: PowerCommand or comparable, AMF-ready
Enclosure: Open skid or acoustic canopy, 75 dB(A) at 7 m
Standards: ISO 8528, IP23 alternator enclosure
Options: ATS panel, bulk tank, battery charger, block heater
Frequency: 50 Hz @ 1 500 rpm
Power factor: 0.8 lagging
Voltage: 400 / 230 V, 3-phase, 4-wire

Description

The C220D5 covers the range most often required for a construction site compound, a processing plant backup, or primary supply where the grid is unreliable. Prime rating is 200 kVA continuous with a 220 kVA standby ceiling. The 6BTAA5.9 engine is the most widely serviced Cummins block in Indonesia, which matters more than headline efficiency: parts and technicians are available in most regional centres. Sets are supplied open-skid or in an acoustic canopy, with an AMF panel and bulk fuel tank quoted as required. We supply the set commissioned with a load-bank test report.
